Super Precision 3-Jaws Wire EDM Dividing Device
► Adopting quality stainless steel with waterproof and robust structure leading lasting durability.
► Special designed SC40 3-Jaw Chuck provide rapid clamping and it suitable for mass production, workpiece with round shaped can precisely & rapidly clamped.
► Torque wrench is included for user-friendly purpose and consistent accuracy performance.
► Adopting high precision double bearings in its structure to achieve higher accuracy, rigidity and stability.
Main parameters:
Center height……………………………………60 ± 0.5mm
Indexer tooth q'ty & accuracy…………24、15° ±5"
Through hole diameters…………………………Ø 21mm
Min. clamping range…………………………………Ø 1mm
Max. clamping range………………………………Ø 25mm
Rotational accuracy………………………………0.003mm
Repeat accuracy…………………………within 0.003mm
► Special designed SC40 3-Jaw Chuck provide rapid clamping and it suitable for mass production, workpiece with round shaped can precisely & rapidly clamped.
► Torque wrench is included for user-friendly purpose and consistent accuracy performance.
► Adopting high precision double bearings in its structure to achieve higher accuracy, rigidity and stability.
Main parameters:
Center height……………………………………60 ± 0.5mm
Indexer tooth q'ty & accuracy…………24、15° ±5"
Through hole diameters…………………………Ø 21mm
Min. clamping range…………………………………Ø 1mm
Max. clamping range………………………………Ø 25mm
Rotational accuracy………………………………0.003mm
Repeat accuracy…………………………within 0.003mm
